Two cylinder Air-cooled diesel generator

Request a Quote Not what you need, please send your RFQs via Email.

Details

Two cylinder Air-cooled diesel generator

Parameter

Two cylinder Air-cooled Diesel generator
Generator Model 8GF-LE 10GF-LE 10GF-LDE
Rated output power(KW) 8 10 10
Max.power(KW) 10 12 12
Rated frequency(Hz) 50/60 50/60 50/60
1-Phase AC voltage 110/220 110/220 110/220
DC output 12V/8.3A 12V/8.3A 12V/8.3A
Power factor(cosāˆ®) 1 1 1
Rated rotation speed(rpm) 3000/3600 3000/3600 3000/3600
Noise level 78 78 70
Fuel tank capacity(L) 30 30 30
Structure type Open Frame type
Engine Engine Model 2V86FE 2V86FE 2V86FE
Type Two cylinder,4-stroke,air-cooled,diesel engine
Displacement(ml) 840 840 840
Max.output power(kw)/Speed(Rpm) 15/3600 15/3600 15/3600
Oil capacity(L) 1.7 1.7 1.7
starting method Electric start
Options 3-Phase Ac voltage Available Available Available
4-wheel vehicle set Available Available Available
2-Wheel and handle Available Available Available
Side panel Available Available Available
Double voltage switch Available Available Available
Remote control system Available Available Available
ATS Available Available Available
Time meter Available Available Available
Pack Packing size(mm) 895x660x885 895x660x885 950x690x915
Net weight(Kgs) 179 179 205
Gross weight(Kgs) 205 205 235
20FT Qty 80 80 70
