Differential Pressure Type Flow Switch

Protection grade

IP54

Maximum permissible static pressure

10bar

Storage temperature

-29~82℃

Maximum permissible differential pressure

5bar

Ambient service temperature

-20~71℃

Repeatability deviation of set point

±1%

Medium service temperature

-20~93℃

Cable details

105℃ Flame-retardant sheathed wire 2×0.75mm2,3×0.75mm2

Output form

10A；125/250VAC；

working medium

Water and air

(Please declare in order, if it’s another medium.)

Side connector of high-low pressure

1/4〞 SAE（7/16〞-20UNF）,1/4〞NPT etc.can bechosen.
