SP304 Series-Special Electric Pump For Hydraulic Wrench
SP304 Series-Special Electric Pump For Hydraulic Wrench Product features: Efficient three-stage flow pressure design, perfect simulation of manual operation, fast...
SP304 Series-Special Electric Pump For Hydraulic Wrench
PDF Datasheet
We can supply according to your requirement.
China SP304 Series-Special Electric Pump For Hydraulic Wrench:
SP304 Series-Special Electric Pump For Hydraulic Wrench
Product features:
Efficient three-stage flow pressure design, perfect simulation of manual operation, fast light load and slow heavy load, bolt pre-tightening more accurate.
The standard configuration also drives two hydraulic wrenches at the same time( another hydraulic wrenches can be configured at the same time)
Aluminum titanium alloy pump body,small quality, portability.
Adjust output pressure freely in the range of 40 to 700bar.
Brushless high-power motor,easy maintenance, long life, motor with starting capacitor can start with load, more concise operation.
| Model | Output Port | Power Parameter | （MPa) Working Pressure | L/min) Flow | Tank Volume (L) | Outer Size (LXWXH) (mm) | Reference Weight (KG) | ||||
| High | Medium | Low | High | Medium | Low | ||||||
| SP304-2 | 4 | 220V/1.1KW | 70 | 32 | 6 | 0.8 | 1.6 | 8 | 7.6 | 394x300x420 | 26 |
| SP304-4 | 8 | 220V/1.1KW | 70 | 32 | 6 | 0.8 | 1.6 | 8 | 7.6 | 394x300x420 | 26 |
