China Solid Polyurethane Fender:

As an alternative to pneumatic rubber buoys, the buoy can meet best quality and performance demands. The manufacturing process of Foam Filled Buoys allows for any size to be constructed and selecting the appropriate grade of foam core and elastomeric skin means the performance of a foam filled buoy can be precisely gauged to meet specific specification requirements.

It is a kind of constructive buoy with polyurea materials as its outer protective layer and EVA foam core forming the resilient inner part. Foam Filled Buoys are constructed of three parts each providing an important function in the construction and lifespan of the buoy. The three parts are closed cell EVA foam,outer rubber + nylon cord fabrics. And Polyurea spraying coat.

There are two types of Foam Filled Buoys, one is CTN Type with chain & tyre net and the other one is Sling Type without chain & tyre net.

Features:

1.High energy absorption with relatively low reaction force. Compared to the typical pneumatic rubber buoys, the same sized Foam Filled Buoys absorb up to 40% more energy. Additionally, the Foam Filled Buoy will not fail if punctured.

2.Foam Filled Buoys can be used in any tough conditions, providing tough, heavy-duty protection for ship-to-ship, ship-to-dock and ship berthing and mooring applications.

3.Easy to maintenance. As the internal construction consists of a solid heat laminated foam core, there is no need to maintain air pressure, inflation, or relief valves as with pneumatic rubber buoys.

4.Tough, nylon filament reinforced polyurea/polyurethane skin,optional Kevlar reinforcement.

The following performance parameters of the "standard" EVA foam filled fenders:

Size

Deflection 60%

Weight(±3%)

Reaction force(KN)

Enery absorption(KJ)

(KG)

300×500

43

5

7

400×800

54

7

17

500×1000

89

32

23

700×1500

129

24

85

1000×1500

190

62

175

1000×2000

298

80

240

1200×2000

335

110

350

1350×2500

460

173

550

1500×3000

615

263

770

1700×3000

678

330

1075

2000×3500

940

535

1530

2000×4000

1095

630

1980

2000×4500

1250

690

2500

2300×4000

1380

735

2885

2300×5500

1860

1133

3480

2500×4000

1455

980

3390

2500×5500

1960

1230

3985

3000×5000

2180

1755

5350

3000×6000

2455

1960

6680

3300×4500

1960

1760

5750

3300×6500

3075

2830

8400

3500×7000

3975

3162

10100

1.The above performance parameters measured are based on static state;
2.Above reaction force and energy absorption tolerance of ± 10%;
3.Special sizes are available upon request processing;
4.Fender accessories have all been hot dip galvanized anti-corrosion treatment
