CB436-2000 A Type Cleat Fairlead With Single Roller
- Category:Warping Roller
- Material:cast steel,cast iron
- Standards:CB436-2000
- Certificate:BV , ABS , CCS, NK, LR, DNV & GL, mill certificate etc.
- Delivery Time:About 15 days.
- Fob Price:Get Latest Price Now
- Place of Origin:China
- Attachment:[pdf]Cb436 2000 A Type Cleat Fairlead With Single Roller.pdf
Details
Product Description:
It is used for guiding ropes in ship mooring and will not breakdown.
Complete with a primer paint finish our Warping Roller (also know as Fairlead roller) are immediately ready for any vessel installation. Cast from the finest quality steel for added durability, our fairlead roller range utilises a combination of horizontal and vertical rollers to give you a comprehensive solution for your needs.
It is used for bollard cable leading of ships
good wear and corrosion resistance to grant a long service time
All products can be designed according to customers requirements.
The breaking load of tight wire is the highest.
Compact design,precision machined smooth surface,easily removable shafts,
Combination type including double warping roller with plate, three warping roller with plate and more.
Paint: Grey Epoxy Primer, for the middle paint and surface according to your requirement.
Delivery time:7-15 days after order be confirmed.
Machining facilities :CNC center, CNC lathes, ultrasonic wave cleaning etc
|
CB436-2000 A type Cleat fairlead with single roller |
||||||||||||||||||||
|
Product No. |
Nominal |
Steel rope GB1102 Breaking Load 1520N/mm2 |
Dimension |
Roller |
Base weight kg H1=1000 |
|||||||||||||||
|
Size(mm) |
6*24 |
6*30 |
6*37 |
D1 |
D2 |
D3 |
D4 |
D5 |
L |
H |
H1 |
H2 |
H3 |
S |
t |
t1 |
Cast iron |
Cast steel |
||
|
CBRA-001 |
150 |
17 |
17.5 |
15 |
240 |
270 |
90 |
71 |
60 |
245 |
211 |
The base height is as per your request |
40 |
75 |
3 |
12 |
8 |
32.1 |
33.8 |
129 |
|
CBRA-002 |
200 |
22.5 |
21.5 |
19.5 |
310 |
340 |
115 |
95 |
80 |
285 |
251 |
50 |
85 |
3 |
14 |
10 |
64.6 |
68 |
178 |
|
|
CBRA-003 |
250 |
24 |
26 |
24 |
380 |
410 |
140 |
107 |
90 |
323 |
298 |
60 |
100 |
4 |
14 |
10 |
108 |
114 |
207 |
|
|
CBRA-004 |
300 |
30 |
32.5 |
28 |
440 |
470 |
160 |
127 |
110 |
355 |
321 |
60 |
100 |
4 |
16 |
14 |
159 |
168 |
265 |
|
|
CBRA-005 |
350 |
37.5 |
39 |
34.5 |
500 |
530 |
180 |
144 |
125 |
390 |
346 |
65 |
100 |
4 |
18 |
14 |
235 |
248 |
332 |
|
|
CBRA-006 |
400 |
41 |
39 |
39 |
560 |
590 |
200 |
161 |
140 |
420 |
371 |
70 |
100 |
5 |
20 |
16 |
336 |
355 |
401 |
|
|
CB436-2000 Atype:Adopt CB 58-83 fairlead roller |
||||||||||||||||||||
