CCFJ30J-W 30-90KW Cummins Series Diesel Generator Set
- Category:Marine Generator
- Certificate:CCS, BV, ABS, GL，LR, NK
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
Cummins series diesel generator set:
Dongfeng Cummins diesel generator set to
choose Dongfeng Cummins B, C, L series diesel engine with Stanford motor,
marathon, Siemens, three wave generator can be selected, such as high
reliability, easy maintenance, low fuel consumption, low noise, large power
output, continuous operation time, global 3 packets of group, etc. As a joint
venture of China and the United States Cummins engine industry's biggest
foreign investors in China, China has the Dongfeng Cummins engine co., LTD
(produce B, C and L series) and Chongqing Cummins engine co., LTD. (production
of N and K series), and other manufacturing enterprises, and to Cummins global
unified quality standard production. Using electronic governor, the cooling
water temperature is too high, low oil pressure and speed alarm and protection
functions such as automatic parking. Cummins company's global service network,
to provide customers with reliable service.
Dongfeng Cummins series of advantages:
25% less than other brand engine parts,
reduces the volume and weight of the diesel engine,
Fuel oil and engine oil channel most drill within the cylinder block and cylinder head,
Stable performance, low failure rate and maintenance cost,
Control system working voltage: 24 v (DV),
Using alloy steel forging crankshaft journal induction hardening,
Most is equipped with the company unique PT fuel system except (B, C series)
Rotary engine oil, diesel oil and water filter, dry type air filter.
Fuel oil and engine oil channel most drill within the cylinder block and cylinder head,
Stable performance, low failure rate and maintenance cost,
Control system working voltage: 24 v (DV),
Using alloy steel forging crankshaft journal induction hardening,
Most is equipped with the company unique PT fuel system except (B, C series)
Rotary engine oil, diesel oil and water filter, dry type air filter.
| Generating set specifications | Diesel Engine Specifications | generator specifications | Size | ||||||||||
| model | Rated power |
Voltage/ frequency Hz/v |
Model | RPM |
Number of Cylinders |
Diameter of cylinder/Stroke(mm) |
displacement (L) |
fuel consumpation (g/kw.h) |
Model |
L*W*H （mm） |
Weight （kg） |
||
| Kw | KVA | Stanford | marathon | ||||||||||
| CCFJ30J-W | 30 | 37.5 | 50/400 | 4BTA3.9-GM47 | 1500 | 4L | 102/120 | 3.9 | 210 | UCM224C | MP-H-30-4 | 1670*850*1270 | 800 |
| CCFJ40J-W | 40 | 50 | 50/400 | 4BTA3.9-GM47 | 1500 | 4L | 102/120 | 3.9 | 210 | UCM224E | MP-H-40-4 | 1760*850*1270 | 800 |
| CCFJ50J-W | 50 | 63 | 50/400 | 6BT5.9-GM83 | 1500 | 4L | 102/120 | 5.9 | 206 | UCM224F | MP-H-50-4 | 1980*895*1300 | 850 |
| CCFJ64J-W | 64 | 80 | 50/400 | 6BT5.9-GM83 | 1500 | 6L | 102/120 | 5.9 | 206 | UCM274C | MP-H-64-4 | 1980*900*1300 | 1000 |
| CCFJ75J-W | 75 | 93.8 | 50/400 | 6BT5.9-GM83 | 1500 | 6L | 102/120 | 5.9 | 206 | UCM274D | MP-H-75-4 | 1980*895*1300 | 1250 |
| CCFJ90J-W | 90 | 113 | 50/400 | 6BTA5.9-GM100 | 1500 | 6L | 102/120 | 5.9 | 206 | UCM274E | MP-H-90-4 | 2080*895*1300 | 1300 |
